Rapid Roll-up Door

The spacious security general space realizes by the Rapid roll-up door!

The Rapid roll-up door can effectively save 85% energy, the realization convenience rapid thing flows the transportation. Rapid roll-up door which completes by the exquisite technology, its remarkable performance has received the widespread approval, Not only in narrow and small spatial internal energy convenience installment; but also cleaner than the iron gate, and more durable.
F E A T U R E

   Model

DM-1000
DM-2000

DM-3000
   Panel

Coating resin PVC
Translucent PVC
Transparent PVC
   Color
Red
Milky yellow
   Width

1500 - 6000 mm
1500 - 5200 mm

1500 - 4500 mm
   Height

1500 - 6000 mm
1500 - 5200 mm

1500 - 4500 mm
   Panel thickness

2 mm
2.5 mm

2.5 mm

   Opening speed

0.8 m/sec
0.8 m/sec

0.8 m/sec
   Environment temperature range
-30°C - 150°C
-70°C - 50°C
-20°C - 50°C
   Wind load
20 m/sec
20 m/sec
20 m/sec
   Power supply
3Ø220 V
3Ø220 V
3Ø220 V
   Additional
      Spring balanced device
      Manual switch during power fail
   Optional
      Wind load device (effective when wind speed at 20 m/sec)
      Opening speed up to 2.5 m/sec
      Aluminum profile
      Explosion-proof
      Cover
